5.0 Configuration Setup
The E810-CQDA2T provides two coaxial input-output SMA connectors, two unidirectional U.FL
connectors and an optional GNSS input connector, as shown in the following two illustrations.
Figure 3. E810-CQDA2T Connector Locations
Figure 4. E810-CQDA2T Connections
SMA1
SMA2
GNSS/SMB
u.FL 2 u.FL 1
Optional GNSS Module
ptp4l
port 1
port2
Grand Server
RU
ptp4l
BBU (BC)
GNSS
ts2phc
GNSS connected to SMA or
onboard GNSS
Backhaul
network
Fronthaul
Backhaul
KPI: Phase Accuracy Target = f 100 ns
