Chapter 1
Introduction of Intel H67/Z68 Chipset Motherboards
1-1 Motherboard Specification
Spec Description
Design
z
ATX form factor; PCB size: 29.5x23cm
Chipset
z
Intel H67/Z68 Express Chipset
CPU Socket
z
Intel LGA 1155 socket Intel® Core™ i7 Processor, Intel® Core™ i5
Processor, Intel® Core™ i3 Processor
* for detailed CPU support information please visit our website
Memory Slots
z
DDRIII module Slots x 4
z
Support 4pcs DDRIII1066/ DDRIII 1333 MHz memory modules
expandable to 16GB.
z
Support Dual- channel function
Expansion Slots
z
1 psc* PCI-Express 2.0 x1 slot
z
1 psc* PCI-Express 2.0 x16 slot by 16 lane
z
1 psc* PCI-Express 2.0 x16 slot by 4 lane
z
1 psc* Mini-PCIE slot
z
1 pcs *32-bit PCI slot
SATA2 & SATA3
z
Supports four internal Serial ATAII ports providing 3.0 Gb/sec data
transfer rate and two SATAIII devices providing 6.0 Gb/sec data
transfer rate
z
Support RAID 0,1,5,10
Gigabit LAN Chip
z
Integrated Gigabit LAN chip
z
Supports Fast Ethernet LAN function provide10Mb/100Mb/ 1Gb /s
data transfer rate
8-CH HD Audio
z
8-channel HD Audio Codec integrated
z
Support 8-channel 3D surround & Positioning Audio
z
Audio driver and utility included
BIOS
z
AMI 32 MB Flash ROM
Multi I/O
z
PS/2 keyboard /mouse portx1
z
VGA port x1
z
DVI port x1
z
HDMI port x1
z
RJ-45 LAN connector x1
z
USB 2.0 port x 6 and USB 2.0 headers x 2
z
USB 3.0 port x 2
z
Audio connector x1 (8-CH Audio)
z
Front panel audio header x1
z
CDIN header x1
z
HDMI-SPDIF header x1
z
Parallel port header x1
z
Serial Port header x1
z
Front panel header x1
z
Power LED header x1
z
Speaker header x 1

Intel H67 Specifications

General

Socket Type	LGA 1155
Memory Type	DDR3
Max Memory Size	32 GB
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 2.0 ports	14
PCIe 3.0 Support	No
Chipset	Intel H67
Integrated Graphics	Yes
