Intel H67 User Manual

3
1-3 Layout Diagram
CPU Socket
A
TX Power Conn.
PCI Slot
CPUFAN1 Header
CDIN Header
Power LED Heade
r
S
p
eake
r
Heade
r
HDMI-SPDIF
Heade
r
Front Panel
Audio Header
USB 2.0
Headers
Front Panel Header
3D Audio Jumper
Line-OUT
SATA3
Ports
ATX 12V
Power Connector
RJ-45 LAN Port
Line-IN
MIC-IN
RS-OUT
CS-OUT
DDR3 Slot x 4
(DIMM1~DIMM4)
SS-OUT
USB 2.0 Ports
Over PS/2 KB/MS
Port
PCI Express 2.0 x16 by 16 Lane
Reset Button
JBAT
Gigabit LAN Chip
8-CH HD
Audio Connecto
r
Power on Button
USB 2.0 Ports
USB 3.0 Port
PS/2 KB/MS
Port
Intel H67/Z68 Chipset
32MB Flash ROM
8-CH HD
Audio Chip
PCI Express2.0 x1
RJ-45 ove
r
USB 2.0 Ports
Debug port
USB 3.0 Ports
USB 2.0 Ports over
HDMI Port
SYSFAN1 Header
Parallel Port Heade
r
Serial Port Header
PCI Express 2.0 x16 by 4 Lane
USB 2.0 Ports
SATA2 Ports
DVI Port
VGA Port
HDMI Port
VGA port over
DVI port
Mini-PCIE Slot
USB 2.0 Ports
Clear CMOS
Button
JP1

Intel H67 Specifications

General

Socket Type	LGA 1155
Memory Type	DDR3
Max Memory Size	32 GB
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 2.0 ports	14
PCIe 3.0 Support	No
Chipset	Intel H67
Integrated Graphics	Yes
