Intel i960 - Memory for Hypothetical Position-Independent Application

i960 Processor Compiler User's Guide
9-4
9
Figure 9-1 shows memory allocation for board 1. When the code
executes, the ROM code for either board loads at the correct address.
Figure 9-1 Memory for Hypothetical Position-independent Application
Slot for Card 2
64 MB
Slot for Card 1
48 MB
Top of RAM
Frame Buffer
Slot RAM
g12
Kernel ROM (code)
0
16 MB
Kernel RAM (data)
Top of Memory
OSD1678
