Power Management

42 Datasheet

NOTE:If enabled, the core C-state will be C1E if all actives cores have also resolved a

core C1 state or higher

4.2.3 Requesting Low-Power Idle States

The primary software interfaces for requesting low power idle states are through the

MWAIT instruction with sub-state hints and the HLT instruction (for C1 and C1E).

However, software may make C-state requests using the legacy method of I/O reads

from the ACPI-defined processor clock control registers, referred to as P_LVLx. This

method of requesting C-states provides legacy support for operating systems that

initiate C-state transitions via I/O reads.

For legacy operating systems, P_LVLx I/O reads are converted within the processor to

the equivalent MWAIT C-state request. Therefore, P_LVLx reads do not directly result in

I/O reads to the system. The feature, known as I/O MWAIT redirection, must be

enabled in the BIOS.

Note: The P_LVLx I/O Monitor address needs to be set up before using the P_LVLx I/O read

interface. Each P-LVLx is mapped to the supported MWAIT(Cx) instruction as follows.

The BIOS can write to the C-state range field of the PMG_IO_CAPTURE MSR to restrict

the range of I/O addresses that are trapped and emulate MWAIT like functionality. Any

P_LVLx reads outside of this range does not cause an I/O redirection to MWAIT(Cx) like

request. They fall through like a normal I/O instruction.

Note: When P_LVLx I/O instructions are used, MWAIT substates cannot be defined. The

MWAIT substate is always zero if I/O MWAIT redirection is used. By default, P_LVLx I/O

redirections enable the MWAIT 'break on EFLAGS.IF’ feature which triggers a wakeup

on an interrupt even if interrupts are masked by EFLAGS.IF.

Table 4-13.Coordination of Thread Power States at the Core Level

Processor Core

C-State

Thread 1

C0 C1 C3 C6

Thread 0

C0 C0 C0 C0

C0 C1

C3 C3

C0 C1

C3 C6

Table 4-14.P_LVLx to MWAIT Conversion

P_LVLx MWAIT(Cx) Notes

P_LVL2 MWAIT(C3) The P_LVL2 base address is defined in the PMG_IO_CAPTURE

MSR, described in the RS - Nehalem Processor Family BWG.

P_LVL3 MWAIT(C6) C6. No sub-states allowed.
