Datasheet 55
Thermal Management
Table 5-18.Intel Pentium P6000 mobile processor series Dual-Core SV Thermal Power
Specifications
5.1.3 Idle Power Specifications
The idle power specifications in Tab l e 5- 17 and Ta b le 5 - 19 are not 100% tested. These
power specifications are determined by the characterization of the processor currents
at higher temperatures and extrapolating the values for the junction temperature
indicated.
Table 5-20.35 W Standard Voltage (SV) Processor Idle Power
5.1.4 Intelligent Power Sharing Control Overview
Based upon knowledge of the processor core and integrated graphics and memory
controller thermal power, performance state, and temperature, power sharing control
does the following:
• Utilizes internal graphics controller dynamic frequency performance states to
achieve their highest performance within the rated thermal power envelope. Intel
TDP
1,2,6,7
Frequency
Power Sharing
Design Points
8
T
j,max
4,5,10,12
Processor
number
State
CPU Core (W)
Int. Gfx & Memory
Controller (w)
Pkg Concurrent
Power (w)
3,13
CPU Core (GHz)
Int. Gfx (MHz)
CPU Core
Extreme (W)
6,7
Int. Gfx
Extreme (W)
6,7
MCP Thermal
Power Limit (W)
CPU Core (ºC)
Int. Gfx & Memory
Controller (ºC)
P6000
HFM 25 12.5 35 1.86
500
up to
667
Proc: 25
Int. Gfx: 10
Proc: 15
Int Gfx:20
35
90 85
LFM 20 12.5 32.5 933 MHz N/A
N/A N/A N/A
Table 5-19.18 W Ultra Low Voltage (ULV) Processor Idle Power
Symbol Parameter Min Typ Max T
j
P
C1E
Idle power in the Package C1e state - - 12 W 50ºC
P
C3
Idle power in the Package C3 state - - 5.0 W 35ºC
P
C6
Idle power in the Package C6 state - - 2.6 W 35ºC
Symbol Parameter Min Typ Max T
j
P
C1E
Idle power in the Package C1e state - - 16 W 50 ºC
P
C3
Idle power in the Package C3 state - - 7.5 W 35 ºC
