Intel PENTIUM P6000 - DATASHEET 2010 - Interface Clocking; Internal Clocking Requirements; Table 2-4 Processor Reference Clocks

Datasheet 35
Interfaces
• Allow communication of processor thermal and other information to the PECI
master.
• Read averaged Digital Thermal Sensor (DTS) values for fan speed control.
2.6 Interface Clocking
2.6.1 Internal Clocking Requirements
§
Table 2-4. Processor Reference Clocks
Reference Input Clocks Input Frequency Associated PLL
BCLK/BCLK# 133 MHz Processor/Memory/Graphics
PEG_CLK/PEG_CLK# 100 MHz PCI Express*/DMI/Intel® FDI
DPLL_REF_SSCLK/DPLL_REF_SSCLK# 120 MHz Embedded DisplayPort* (eDP)
