Intel PENTIUM P6000 - DATASHEET 2010 - Embedded Displayport (Edp); Intel Flexible Display Interface Signals; Table 6-27 Intel Flexible Display Interface

Datasheet 75
Signal Description
6.5 Embedded DisplayPort (eDP)
6.6 Intel Flexible Display Interface Signals
Embedded Display Port Signals
Signal Name Description
Direction/Buffer
Type
eDP_TX[3:0]
eDP_TX#[3:0]
Embedded DisplayPort Transmit Differential
Pair: Nominally, eDP_TX[3:0] is multiplexed
with PEG_TX[12:15] and eDP_TX#[3:0] is
multiplexed with PEG_TX#[12:15]. When
reversed, eDP_TX[3:0] is multiplexed with
PEG_TX[3:0] and eDP_TX#[3:0] is multiplexed
with PEG_TX#[3:0]
O
PCI Express
eDP_AUX
eDP_AUX#
Embedded DisplayPort Auxiliary Differential
Pair: Nominally, eDP_AUX is multiplexed with
PEG_RX[13] and eDP_AUX# is multiplexed
with PEG_RX#[13]. When reversed, eDP_AUX
is multiplexed with PEG_RX[2] and eDP_AUX#
is multiplexed with PEG_RX#[2]
I/O
PCI Express
eDP_HPD# Embedded DisplayPort Hot Plug Detect:
Nominally, eDP_HPD# is multiplexed with
PEG_RX[12]. When reversed, eDP_HPD# is
multiplexed with PEG_RX[3]
I
PCI Express
eDP_ICOMPI Embedded DisplayPort Input Current
Compensation: Multiplexed with PEG_ICOMPI
I
A
eDP_ICOMPO Embedded DisplayPort Output Current and
Resistance Compensation: Multiplexed with
PEG_ICOMPO
I
A
eDP_RCOMPO Embedded DisplayPort Resistance
Compensation: Multiplexed with PEG_RCOMPO
I
A
eDP_RBIAS Embedded DisplayPort Resistor Bias Control:
Multiplexed with PEG_RBIAS
I
A
Table 6-27.Intel® Flexible Display Interface (Sheet 1 of 2)
Signal Name Description
Direction/Buffer
Type
FDI_TX[3:0]
FDI_TX#[3:0]
Intel® Flexible Display Interface
Transmit Differential Pair - Pipe A
O
FDI
FDI_FSYNC[0] Intel® Flexible Display Interface Frame
Sync - Pipe A
I
CMOS
FDI_LSYNC[0] Intel® Flexible Display Interface Line Sync
- Pipe A
I
CMOS
