Intel PENTIUM P6000 - DATASHEET 2010 - Table 8-51 BGA1288 Processor Ball List by Ball Name

Datasheet 141
Processor Pin and Signal Information
Table 8-51.BGA1288 Processor Ball
List by Ball Name
(Sheet 1 of 37)
Pin Name Pin #
Buffer
Type
Dir
BCLKAC71
AK7 DIFF
CLK
I
BCLK # AK8 DIFF
CLK
I
BCLK_ITP K71 DIFF
CLK
O
BCLK_ITP # J70 DIFF
CLK
O
BPM#[0] J69 GTL I/O
BPM#[1] J67 GTL I/O
BPM#[2] J62 GTL I/O
BPM#[3] K65 GTL I/O
BPM#[4] K62 GTL I/O
BPM#[5] J64 GTL I/O
BPM#[6] K69 GTL I/O
BPM#[7] M69 GTL I/O
CATERR# N61 GTL I/O
CFG[0] AL4 CMOS I
CFG[1] AM2 CMOS I
CFG[2] AK1 CMOS I
CFG[3] AK2 CMOS I
CFG[4] AK4 CMOS I
CFG[5] AJ2 CMOS I
CFG[6] AT2 CMOS I
CFG[7] AG7 CMOS I
CFG[8] AF4 CMOS I
CFG[9] AG2 CMOS I
CFG[10] AH1 CMOS I
CFG[11] AC2 CMOS I
CFG[12] AC4 CMOS I
CFG[13] AE2 CMOS I
CFG[14] AD1 CMOS I
CFG[15] AF8 CMOS I
CFG[16] AF6 CMOS I
CFG[17] AB7 CMOS I
COMP0 AE66 Analog I
COMP1 AD69 Analog I
COMP2 AC70 Analog I
COMP3 AD71 Analog I
DBR# W71 O
DC_TEST_A5 A5
DC_TEST_A68 A68
DC_TEST_A69 A69
DC_TEST_A71 A71
DC_TEST_BR1 BR1
DC_TEST_BR71 BR71
DC_TEST_BT1 BT1
DC_TEST_BT3 BT3
DC_TEST_BT69 BT69
DC_TEST_BT71 BT71
DC_TEST_BV1 BV1
DC_TEST_BV3 BV3
DC_TEST_BV5 BV5
DC_TEST_BV68 BV68
DC_TEST_BV69 BV69
DC_TEST_BV71 BV71
DC_TEST_C3 C3
DC_TEST_C69 C69
DC_TEST_C71 C71
DC_TEST_E1 E1
DC_TEST_E71 E71
DMI_RX[0] F9 DMI I
DMI_RX[1] J6 DMI I
DMI_RX[2] K9 DMI I
DMI_RX[3] J2 DMI I
DMI_RX#[0] F7 DMI I
DMI_RX#[1] J8 DMI I
DMI_RX#[2] K8 DMI I
DMI_RX#[3] J4 DMI I
DMI_TX[0] G17 DMI O
DMI_TX[1] M15 DMI O
DMI_TX[2] G13 DMI O
Table 8-51.BGA1288 Processor Ball
List by Ball Name
(Sheet 2 of 37)
Pin Name Pin #
Buffer
Type
Dir
