Intel® Server S2600WF Product Family Configuration Guide
23
Intel® Server Board Feature
S2600WFT(R)
S2600WF0(R)
S2600WFQ(R)
Video
•
Integrated 2D video controller
• 16MB of DDR4 video memory
• (1) – DB-15 external connector
• (1) – 14-pin internal connector for optional front panel video support
USB
• (3) – external USB 3.0 ports
• (1) – internal type-A USB 2.0 port
• (1) – internal 20-pin connector for optional 2x USB 3.0 port front panel support
•
(1) – internal 10-pin connector for optional 2x USB 2.0 port front panel support
Serial Port
• (1) – external RJ-45 serial-A port connector
• (1) – internal DH-10 serial-B port header for optional front or rear serial port support
Server Management
• Integrated baseboard management controller, IPMI 2.0 compliant
• Support for Intel® Server Management software
• Dedicated onboard RJ45 management port
• Advanced server management via Intel® RMM4 Lite – iPC AXXRMM4LITE2 (accessory option)
Security
• Trusted platform module 2.0 (Rest of World) – iPC AXXTPMENC8 (accessory option)
• Trusted platform module 2.0 (China Version) – iPC AXXTPMCHNE8 (accessory option)
System Fan
• (6) – system fans supported in two different connector formats: hot swap (2U) and cabled (1U)
o (6) – 10-pin managed system fan headers (sys_fan 1-6) – used for 1U system configuration
o (6) – 6-pin hot swap capable managed system fan connectors (sys_fan 1-6) – used for 2U system configuration
1 Intel® Optane™ persistent memory module is supported only by Intel® Server Boards S2600WFTR, S2600WF0R, and S2600WFQR with 2
nd
Gen Intel® Xeon® Scalable processor.
