Intel® Server S2600WF Product Family Configuration Guide
25
Table 6. Intel® Server Board S2600WFTF product family features
Intel® Server Board Feature
• (2) – LGA3647-0 (Socket P) processor sockets
• Supports (1) or (2) of the following processors from the Intel® Xeon® processor Scalable family
o Intel® Xeon® Silver 4106H processor
o Intel® Xeon® Gold 6130H processor
o Intel® Xeon® Platinum 8160H processor
• (24) – total DIMM slots (12 per processor)
o (6) – memory channels per processor
o (2) – DIMMs per channel
• Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
• Memory data transfer rates up to 2666 MT/s (dependent on processor)
• DDR4 standard voltage of 1.2 V
Intel® C62x Series Chipset
Intel® Platform Firmware Resilience
Intel® Quick Assist Technology
Intel® Omni-Path Fabric Support
• Dual Port 10Gb RJ45 – iPC 557T2OCPG1P5
• Dual Port SFP+ – iPC 527DA2OCPG1P5
Intel® Integrated SAS Module
Onboard PCIe* NVMe* Support
• (4) – OCuLink connectors
• Intel® VMD support
•
Intel® RSTe/Intel® VROC support (accessory option)
• (12) – SATA 6 Gbps ports (6 Gb/s, 3 Gb/s and 1.5 Gb/s transfer rates supported)
o (2) – single port 7-pin SATA connectors
o (2) – M.2 connectors – SATA / PCIe*
o (2) – 4-port mini-SAS HD (SFF-8643) connectors
• Embedded SATA Software RAID
o Intel® RSTe 5.0
o Intel® Embedded Server RAID Technology 2 1.60 with optional RAID 5 key support
Concurrent support for up to three riser cards
• Riser #1 – PCIe* 3.0 x24 (CPU1 x16, CPU2 x8) – 2 and 3 slot riser card options available
• Riser #2 – PCIe* 3.0 x24 (CPU2 x24) – 2 and 3 slot riser card options available
•
Riser #3 (2U systems only) – PCIe* 3.0 (CPU 2 x12) – 2 slot riser card available (low-profile add-in cards only)
• Integrated 2D video controller
• 16MB of DDR4 video memory
• (1) – DB-15 external connector
•
(1) – 14-pin internal connector for optional front panel video support
