Intel R1000WF Series User Manual

Intel® Server S2600WF Product Family Configuration Guide
29
Table 7. Intel® Server System R1000WF product family features
Feature
Description
Chassis Type
1U rack mount chassis
Server Board
Intel® Server Board S2600WF product family
Maximum Supported Processor Thermal
Design Power (TDP)
Up to 165 W
Note: Intel® Server Systems in this family may support a lower maximum Thermal Design Power (TDP). See the appropriate Intel®
System TPS for maximum supported TDP.
External I/O Connections
• DB-15 video connectors
o Front and back
• RJ-45 serial port A connector on back panel
• Dual RJ-45 network interface connectors (S2600WFT-based systems only)
• Dedicated RJ-45 server management port on back panel
• (3) – USB 3.0 connectors on back panel
•
(2) – USB 3.0 connectors on front panel (non-storage system configurations only)
Internal I/O Connectors/Headers
• (1) – Type-A USB 2.0 connector
•
(1) – DH-10 serial port B connector
System Fans
• (6) – managed 40 mm dual rotor system fans
• One power supply fan for each installed power supply module
Riser Card Support
Support for two riser cards:
• Riser #1 – PCIe* 3.0 x24
• Riser #2 – PCIe* 3.0 x24
With two riser cards installed, up to two possible add-in cards can be supported (one x16 PCIe* 3.0 add-in card slot per riser card):
• (2) full height/half-length add-in cards via Risers #1 and #2
Power Supply Options
The server system can have up to two power supply modules installed, providing support for the following power configurations:
1+0, 1+1 redundant power, and 2+0 combined power.
(3) power supply options:
• AC 1100 W Platinum
• AC 1300 W Platinum
• DC 750 W Gold
Drive Bay Options
• Hot-swap backplane options:
o 4 x 3.5” SAS/SATA backplane
o 8 x 2.5” combo backplane – SAS/SATA/NVMe
Note: All available backplane options have support for SAS 3.0 (12 Gb/sec).
• Storage bay options:
o 4 x 3.5” SAS/SATA hot swap drive bays + front panel I/O
o 8 x 2.5” SAS/SATA/NVMe* hot swap drive bays + front panel I/O
Supported Rack Mount Kit Accessory
Options
• AXXELVRAIL – Enhanced value rack mount rail kit – 424 mm max travel length, 59 kg max supported weight
• A1UFULLRAIL – 1U premium rail kit with CMA support – 780 mm max travel length, 18 kg max supported weight
• A1USHRTRAIL – 1U premium rail kit without CMA support – 780 mm max travel length, 18 kg max supported weight
• AXX2POSTBRCKT – Two post fixed mount bracket kit
• AXX1U2UCMA2– Cable management arm (CMA) (supported with AXXFULLRAIL only)
