8.5.6 USB Connector
The Server Board S1200SP Series provide:
 One 2x5 pin USB 2.0 header, providing front panel support for two USB ports respectively
 One 2x10 pin USB 3.0 header on S1200SPL and S1200SPO, providing front panel support for two USB
3.0 ports respectively (P4000XXSFDR chassis)
 2x USB 2.0 ports at the back of the board
 2x USB 3.0 ports at the back of the board
 1x internal Type-A USB 2.0 port to support the installation of a USB device inside the server chassis
Table 41. USB 2.0 FP Header (J1J2)
Pin
IO
Signal Name
Pin
IO
Signal Name
1
PWR
P5V_AUX
2
PWR
P5V_AUX
3
IO
USB_N
4
IO
USB_N
5
IO
USB_P
6
IO
USB_P
7
GND
GND
8
GND
GND
9
NC
Key Pin
10
NC
NC
Table 42. USB3.0 FP Header (J1J1)
Pin
IO
Signal Name
Pin
IO
Signal Name
1
PWR
P5V_AUX
key
NC
KEY
2
O
USB3_RX_DN
19
PWR
P5V_AUX
3
O
USB3_RX_DP
18
O
USB3_RX_DN
4
GND
GND
17
O
USB3_RX_DP
5
I
USB3_TX_DN
16
GND
GND
6
I
USB3_TX_DP
15
I
USB3_TX_DN
7
GND
GND
14
I
USB3_TX_DP
8
IO
USB2_DN
13
GND
GND
9
IO
USB2_DP
12
IO
USB2_DN
10
O
TP_USB3_ID
11
IO
USB2_DP
Table 43. USB 2.0 Connector (Rear IO) (J6A1)
Pin
IO
Signal Name
Pin
IO
Signal Name
1
PWR
P5V_AUX
5
PWR
P5V_AUX
2
IO
USB2_DN
6
IO
USB2_DN
3
IO
USB2_DP
7
IO
USB2_DP
4
GND
GND
8
GND
GND
Table 44. Internal Type A USB Port Pin-out (J1K3)
Pin
IO
Signal Name
1
PWR
P5V_AUX
2
IO
USB2_DN
3
IO
USB2_DP
4
GND
GND
