Appendix B: Compatible Intel® Server Chassis Intel® Server Board S2600CO Family TPS
Revision 1.4
Intel order number G42278-004
118
Configuration P4308XXMFEN P4308XXMHEN P4308XXMFGN P4308XXMHGC P4308XXMHJC
activity LED, System status LED, two USB ports, Optional front serial port/VGA port
Appearance Color: Cosmetic black (GE 701 or equivalent), service Intel
®
blue, hot swap Intel
®
green.
Support for Intel
®
standard front panel or LCD
Dimensions
Pedestal
17.24 in (438 mm) x 6.81 in (173mm) x 25 in (612 mm) (Height X Width X Depth)
Optional
Accessory
Kits
Zephyr flash storage, RMM4-lite modules, TPM module, dedicated NIC module, Expander Card module,
Configuration P4208XXMHEN P4208XXMHDR P4208XXMHGR P4208XXMHGC P4216XXMHJC
Intel
®
Server
Board
Support
 Intel
®
Server Board S2600CP
 Intel
®
Server Board S2600CO
 Intel
®
Server Board S2400SC
 Intel
®
Server Board S2400GP
Power 550W non-
redundant
fixed power
supply
Two 460W
redundant hot-
swap power
supply with
low current
PDB
Two 750W redundant hot-swap
power supply with high current
PDB
Two 1200W redundant hot-
swap power supply with high
current PDB
System
Cooling
Two 120x38mm non-redundant fans Five 80x38mm redundant hot swap fans
Peripherals
Bays
Three (3) half height 5-1/4" bays for optical devices.
Drive Bays Include one 8x2.5” hot-swap hard drive cage. Supports up to eight
2.5” hot-swap hard drives.
Include two 8x2.5” hot-swap
hard drive cage. Supports up to
sixteen 2.5” hot-swap hard
drives.
Expansion
Slots
Support up to six (6) full height, full length PCI form factor cards mechanically
Front Panel Power Button with LED, Reset Button, NMI Button, ID Button with LED, Four NIC LEDs, Hard drive
activity LED, System status LED, two USB ports, Optional front serial port/VGA port
Appearance Color: Cosmetic black (GE 701 or equivalent), service Intel
®
blue, hot swap Intel
®
green.
Support for Intel
®
standard front panel or LCD
Dimensions
Pedestal
17.24 in (438 mm) x 6.81 in (173mm) x 25 in (612 mm) (Height X Width X Depth)
Optional
Accessory
Kits
Zephyr flash storage, RMM4-lite modules, TPM module, dedicated NIC module, Expander Card module
Configuration P4216XXMHGC P4216XXMHGR P4308XXMHGR P4308XXMFGR P4308XXMHGN
Intel
®
Server
Board
Support
 Intel
®
Server Board S2600CP
 Intel
®
Server Board S2600CO
 Intel
®
Server Board S2400SC
 Intel
®
Server Board S2400GP
Power Two 750W redundant hot-swap power supply with high current PDB One 750W hot-swap power
supply with high current PDB
System
Cooling
Five 80x38mm
redundant hot
swap fans
Two 120x38mm non-redundant fans
Peripherals
Bays
Three (3) half height 5-1/4" bays for optical devices.
Drive Bays Include two 8x2.5” hot-swap
hard drive cage. Supports up to
Include one
8x3.5” hot-
Includes one
fixed drive
Include one 8x3.5” hot-swap
hard drive cage. Supports up to

Intel S2600CO series Specifications

General

Brand	Intel
Model	S2600CO series
Category	Server Board
Language	English
