Product Overview Intel® Server Board S2600CO Family TPS
6 Revision 1.4
Intel order number G42278-004
Callout Description Callout Description
double width card
F Battery AM Main Power
G Slot 4, PCI Express* Gen3 AN
USB_4 (Internal Type A USB
Connector)
H
Slot 5, PCI Express* Gen3 (blue slot), supports
double width card
AO Storage Upgrade key connector
I Slot 6, PCI Express* Gen3 AP*
FAN BOARD_I
2
C (Intel
Server
Board S2600CO4 only)
J DIMM E1/E2/F1/F2 AQ SATA_0 connector
K Status LED AR SATA_1 Connector
L ID LED AS SAS/SATA_7 Connector
M Diagnostic LED AT SAS/SATA_6 Connector
N NIC 3/4 AU SAS/SATA_5 Connector
O USB 0/1/2/3, NIC 1,2 AV SAS/SATA_4 Connector
P VGA AW SAS/SATA_3 Connector
Q CPU 2 Power connector AX SAS/SATA_2 Connector
R System Fan 7 AY SAS/SATA_1 Connector
S Serial Port A AZ SAS/SATA_0 Connector
T CPU 2 Fan Connector BA SAS SGPIO 0
U DIMM H1/H2/G1/G2 BB SAS SGPIO 1
V DIMM A1/A2/B1/B2 BC IPMB
W CPU 1 Power connector BD HSBP_I
2
C
X CPU 1 Fan Connector BE USB 5-6 (front panel USB connector)
Y DIMM C1/C2/D1/D2 BF ME Force Update
Z USB port to support SSD BG BMC Force Update
AA HDD LED Header BH**
IEEE_1394B_0 Connector (Intel
Server Board S2600COE only)
AB TPM Connector BI Password Clear
AC System Fan 6 Connector BJ BIOS Recovery
AD System Fan 5 Connector BK**
IEEE_1394B_1 Connector (Intel
Server Board S2600COE only)
AE System Fan 4 Connector BL Serial B connector
AF System Fan 3 Connector BM RMM4 NIC
AG System Fan 2 Connector BN SSI Front Panel
Figure 1. Major Board Components
