Appendix D: Intel® Server Board S2600CO Family Specific Sensors Intel® Server Board S2600CO Family TPS
Revision 1.4
Intel order number G42278-004
136
Chassis
Fan Domain
Major Components Cooled
(Temperature sensor number)
Fans
(Sensor number)
 P1 Therm Margin (74h)
 P2 Therm Margin (75h)
 DIMM Thrm Mrgn 1 (B0h)
 DIMM Thrm Mrgn 2 B1h)
 DIMM Thrm Mrgn 3 (B2h)
 DIMM Thrm Mrgn 4 (B3h)
4
 BB P2 VR Temp (24h)
 HSBP 1 Temp (29h)
 HSBP 2 Temp (2Ah)
 Exit Air Temp (2Eh)
 PS1 Temperature (5Ch)
 PS2 Temperature (5Dh)
 P2 Therm Margin (75h)
 DIMM Thrm Mrgn 1 (B0h)
 DIMM Thrm Mrgn 4 (B3h)
System Fan 5 (34h)
HSC Availability
 Intel
®
Server Chassis P4208(UPM)
o 8-bay 2.5'' HDD – FXX8X25HSBP
 Intel
®
Server Chassis P4216 (UPM)
o 8-bay 2.5'' HDD – FXX8X25HSBP
 Intel
®
Server Chassis P4304(UPM)
o 4-bay 3.5'' HDD – FUP4X35HSBP
 Intel
®
Server Chassis P4308 (UPM)
o 8-bay 3.5'' HDD – FUP8X35HSBP
Power unit support
 Intel
®
Server Chassis P4208/P4216/P4304/P4308 (Intel
®
Server Chassis P4000M
Family)
Table 72. Power Supply Support
PS Module
Number
PMBus*
Product Name (in
product area of the
FRU)
PSU Redundant
Cold
Redundant
Fans in
each PS
460W HS
Power Supply
Supported
DPS-460KB A
Not supported
(One PSU
configuration)
Not
supported
1 PS fan
460W HS
Power Supply
Supported
DPS-460KB A Supported Supported 1 PS fan
550W Fixed
Power Supply
Not
supported
No FRU Not supported Not
supported
NA
750W HS
Power Supply
Supported
DPS-750XB A
Not supported
(One PSU
configuration)
Not
supported
1 PS fan
750W HS
Power Supply
Supported DPS-750XB A Supported Supported 1 PS fan
