Intel® Server Board S2600CO Family TPS Appendix D: Intel® Server Board S2600CO Family Specific Sensors
Revision 1.4
Intel order number G42278-004
133
Appendix D: Intel
®
Server Board S2600CO Family Specific
Sensors
Product ID
Bytes 11:12 (product ID) of Get Device ID command response: 5Dh 00h
ACPI S3 Sleep State Support
Not supported.
Processor Support for Intel
®
Server Board S2600CO
 Intel
®
Xeon
®
processor E5-2600 or E5-2600 v2 product family up to 150 W
 Intel
®
Xeon
®
processor E5-2600 or E5-2600 v2 product family up to 150 W
Supported Chassis
 Intel
®
Server Chassis P4208 (UPM with fixed fan 4U/general SKU)
 Intel
®
Server Chassis P4216 (UPM with fixed fan 4U/general SKU)
 Intel
®
Server Chassis P4304 (UPM with fixed fan 4U/general SKU)
 Intel
®
Server Chassis P4308 (UPM with fixed fan 4U/general SKU)
 Intel
®
Server Chassis P4208 (UPM with fixed fan 4U/150W SKU)
 Intel
®
Server Chassis P4216 (UPM with fixed fan 4U/150W SKU)
 Intel
®
Server Chassis P4308 (UPM with fixed fan 4U/150W SKU)
 Intel
®
Server Chassis P4208 (UPM with redundant fan 4U)
 Intel
®
Server Chassis P4216 (UPM with redundant fan 4U)
 Intel
®
Server Chassis P4308 (UPM with redundant fan 4U)
Table 70. Chassis-specific Sensors
Intel
®
Server Chassis Fan Tachometer sensors Fan Presence sensors Physical security
(Chassis intrusion)
Sensor
FP interrupt (FP NMI
Diag Int)
P4208/P4216/P430
4/P4308 (UPM with
fixed fan
4U/general SKU)
System Fan 1 (30h)
NA Physical Scrty (04h) FP NMI Diag Int (05h)
System Fan 2 (31h)
NA NA NA
P4208/P4216/P430
8 (UPM with fixed
fan 4U/150W SKU)
System Fan 1 (30h)
NA Physical Scrty (04h) FP NMI Diag Int (05h)
System Fan 2 (31h)
NA NA NA
Processor 1 Fan (36h)
NA NA NA
Processor 2 Fan (37h)
detected
NA NA NA
P4208
/P4216/P4308
(UPM with
redundant fan 4U)
System Fan 1 (30h) Fan 1 Present (40h)
Physical Scrty (04h) FP NMI Diag Int (05h)
System Fan 2 (31h) Fan 2 Present (41h)
NA NA
System Fan 3 (32h) Fan 3 Present (42h)
NA NA
System Fan 4 (33h) Fan 4 Present (43h)
NA NA
System Fan 5 (34h) Fan 5 Present (44h)
NA NA
