Intel® Server Board S2600CO Family TPS Product Overview
Revision 1.4 5
Intel order number G42278-004
2.1 Server Board Connector and Component Layout
The following illustrations provide a general overview of the server board, identifying key feature
and component locations. Each connector and major component is identified by a number or
letter, and the description is given below the figure.
Callout Description Callout Description
A Chassis Intrusion AH System Fan 1 Connector
B Slot1, PCI Express* Gen2 AI LCP
C RMM4 Lite AJ Optional 12V Power Connector
D Slot 2, PCI Express* Gen3 AK BIOS Default
E
Slot 3, PCI Express* Gen3 (blue slot), supports
AL SMB_PMBUS*
