Intel S2600CO series User Manual

Intel® Server Board S2600CO Family TPS Product Overview
Revision 1.4 3
Intel order number G42278-004
2. Product Overview
The Intel
®
Server Board S2600CO is a monolithic printed circuit board (PCB) assembly with
features designed to support the pedestal server markets. It has two board SKUs, namely
S2600CO4 and S2600COE. These server boards are designed to support the Intel
®
Xeon
®
Processor E5-2600 or E5-2600 v2 product family. Previous generation Intel
®
Xeon
®
processors
are not supported. Many of the features and functions of these two SKUs are common. A board
will be identified by the name when a described feature or a function is unique to it.
Table 1. Intel
®
Server Board S2600CO Family Feature Set
Feature Description
Processor Support  Two LGA 2011 (Socket R) processor sockets
 S2600CO4 - Support for one or two Intel
®
Xeon
®
Processor(s) E5-2600 or E5-2600
v2 product with a Thermal Design Power (TDP) of up to 135W.
 S2600COE - Support for one or two Intel
®
Xeon
®
Processor(s) E5-2600 or E5-2600
v2 product family with a Thermal Design Power (TDP) of up to 150W with possible
configuration limits.
Memory  16 DIMM slots – 2 DIMM slots/channel – 4 memory channels per processor
 Channels A, B, C, D, E, F, G and H
 Support for Registered DDR3 Memory (RDIMM), LV-RDIMM, Unbuffered DDR3
memory ((UDIMM) with ECC and Load Reduced DDR3 memory (LR-DIMM)
 Memory DDR3 data transfer rate of 800, 1066, 1333,1600 and1866 MT/s
 DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V
Chipset Intel
®
C600-A chipset with support for optional Storage Option Select keys
Rear I/O connections  One DB15 Video VGA connector
 One DB9 Serial connector
 Four USB 2.0 connectors
 Four RJ-45 Network Interface Connectors supporting 10/100/1000Mb
Internal I/O
connectors/headers
 One 2x5 pin connector providing front panel support for two USB ports
 One internal type A USB 2.0 connector
 One internal low-profile 2mm USB port for USB Solid State Drive
 One 2x15 pin SSI-EEB compliant front panel connector
 One DH-10 Serial Port B connector
 Two internal IEEE 1394b connectors (Intel
®
Server Board S2600COE only.)
Cooling Fan Support  Two 4-pin managed CPU fan headers
 Six 6-pin managed system fan headers
 One 4-pin managed rear system fan header
 One 4-pin I
2
C header that is intended to be used for third party fan control circuits
using a Maxim 72408 controller (Intel
®
Server Board S2600CO4 only.)
