Intel® Server S2600WF Product Family Configuration Guide
136
Details
Description
High Airflow Air Duct Bracket Kit
iPC
AWFCOPRODUCTBKT
MM#
961675
UPC
00735858351720
EAN
5032037109949
MOQ
1
Product type
2U accessory kit
Required 2U accessory kit when installing an Intel® Xeon Phi™ coprocessor card with passive
heat sink (heat sink only, no fan) or non-Intel GPGPU with passive heat sink.
Kit includes:
(1) – Metal shipping bracket
(2) – Non-Intel GPGPU secure mounting adapters
Note: Intel Xeon Phi cards with active heat sinks are NOT supported in systems confgured with
the high airflow air duct.
Note: Systems configured with any type of Intel® Xeon Phi™ card and/or non-Intel GPGPU card
must have the shipping bracket installed before the system is exposed to any level of shock or
vibration or is shipped to the end user location. Failure to install the shipping bracket has the
potential to cause serious damage to various components within the system.
Additional required accessory:
High Airflow Duct Kit which includes a high flow air duct – iPC AWFCOPRODUCTAD
2-slot PCIe* Riser card option which includes a 2-slot riser PCBA and a 12V AUX power cable –
iPC A2UL16RISER2

Intel S2600WF Series Specifications

General

Form Factor	2U rackmount
Memory Support	DDR4 ECC Registered DIMMs
Chipset	Intel C621
Storage Options	SATA, SAS, NVMe (depending on the specific model)
Management	Intel Node Manager
Product Type	Server Motherboard / System
CPU Socket Type	LGA 3647
Memory Type	DDR4 ECC Registered
Storage Controllers	Intel VROC
SATA Ports	10 SATA3 ports
Network Controller	Intel i350-AM4
Expansion Slots	7 x PCIe 3.0 slots (x16, x8, x4)
SAS Ports	Support through optional add-on cards
