Intel S2600WF Series User Manual

Intel® Server S2600WF Product Family Configuration Guide
3
Document Revision History
Date Published
Revision
Revision Change Description
June 2017
1.0
Production release
July 2017
1.1
Updated iPC A2U8X25S3DPDK2
Updated cable kit information for 4 port switch for 1U systems
Added 1U and 2U back panel illustrations in section 1.2 and 1.3
Updated A2UHANDLKIT illustration in sections 6 and 7
Added Intel® Visual Compute Accelerators VCA1585LMV in section 8
August 2017
1.2
Updated product ordering information for AXXRMM4LITE2
Updated cables required for second fabric processor with AWF1PFABKITM and AWF1PFABKITP
Updated product ordering information for AXXRMFBU6
Updated RAID information in section 5
Updated note for R2000WFXXX description, deleted optical drive support
Removed A2UHANDLKIT3 handle
Updated SAS drive configuration note
Updated 2U system information on hot-swap drive bays F2U12X35S3PH
Updated information in table Drive Bay #1, 2 & 3 - SAS / SATA / NVMe Cable Guide for Switch Add in Cards
Updated RAID information on Intel® Server Board S2600WFT to include Intel® Embedded Server RAID Technology 2 1.60
with optional RAID 5 key support
Updated Images: A2U8X25S3DPDK2, A2U8X25S3PHS, A2UREARHSDK2
October 2017
1.3
Added Intel® Server Board S2600WFQ information throughout document
Added R2312WFQZS to the section 2U 12 x 3.5” - R2312WFxxx SAS / SATA Data Cable Guide (with No SAS Expander)
Added R2312WFQZS to the section 2U 12 x 3.5” - R2312WTxxx SAS / SATA Data Cable Guide (with SAS Expander)
Updated 2U systems have three riser card A2UL8RISER2 included on the configuration
Updated product ordering information for RSP3MD088F
Updated chipset information for S2600WFQ on the table The Intel® Server Board S2600WF family
Updated chipset information and notes for Intel Server Board S2600WFQ
Updated order code Information for R2312WFQZS
Updated resources in Table 4
Updated image for X527DA40CPG1P5
Updated product name for AXX1300TCRPS
Updated label OCP* module note for all 1U and 2U systems
Added a note of only S2600WF0 and S2600WFQ support on the quad OCP* expansion modules
Added note for AWF1PFABKITM and AWF1PFABKITP
Added adjustment note for A1UFULLRAIL, A1USHRTRAIL, AXXFULLRAIL, AXXSHRTRAIL
Added 1 x A2UX8X4RISER on the 2U systems: R2312WF0NP, R2312WFTZS, R2312WFQZS, R2224WFQZS, R2224WFTZS
Updated SAS/SATA/NVMe* Data Cable Guide section
Corrected all 2U system BOMs and product feature reference tables to include third riser card option
October 2017
1.3.1
Corrected kit content definitions for the two IFT Carrier Accessory Kits
Added 1U/2U fabric CPU clip accessory kit FXXCPUCLIPF
Made additional corrections/clarification to NVMe* cable guide sections.
Updated chassis illustrations in cable guide sections

Intel S2600WF Series Specifications

General

Brand	Intel
Model	S2600WF Series
Category	Server
Language	English
