Intel S2600WF Series User Manual

Intel® Server S2600WF Product Family Configuration Guide
96
Table 58. Data cable guide (with SAS expander) for Intel® Server System R2312WFxxx
System
Configuration
Drive Support
SATA
Onboard Multi-port SATA
Ports
SAS + Expander
Mezzanine 12Gb SAS ROC
Module + 12 Gb SAS Expander
to Backplane (BP)
SAS + Expander
12Gb SAS RAID PCIe* add-in
card + 12 Gb SAS Expander to
Backplane (BP)
Up to 2 x NVMe*
Cables for Onboard PCIe*
OCuLink to Backplane (BP) drive
bays 10 & 11 only
R2312WF…
12 x 3.5”
6 Gb SATA all drives
12 Gb SAS all drives
PCIe NVMe SFF
drives 10 & 11 only
Onboard SATA controllers do
not support SAS expanders.
If attaching the onboard SATA
controller to the Backplane,
then use cables that are
included in the System SKUs.
For building block integration
use cable kits:
AXXCBL800HDHD
AXXCBL875HDHD
With 12 Gb SAS Expander
RES3FV288 installed in Riser
#1:
Use cables in Expander Kit to
attach SAS ROC to Expander
Card
Use the following cables to
attach Expander to Backplane:
Expander

BP 0-3
800 mm HD --– HD
Expander

BP 4-7
875 mm HD --- HD
Expander

BP 8-11
950 mm HD ---HD
From data above, select
appropriate cable kits from list
below:
AXXCBL800HDHD
AXXCBL875HDHD
AXXCBL950HDHD
L6 systems ship with 1 each of
the cables listed.
With 12 Gb PCIe RAID and 12
Gb SAS Expander RES3FV288
installed in riser #1:
Use cables in Expander Kit to
attach PCIe SAS card to
Expander Card
Use the following cables to
attach Expander to Backplane:
Expander

BP 0-3
800 mm HD --– HD
Expander

BP 4-7
875 mm HD --- HD
Expander

BP 8-11
950 mm HD ---HD
From data above, select
appropriate cable kits from list
below:
AXXCBL800HDHD
AXXCBL875HDHD
AXXCBL950HDHD
PCIe SSD3 (CR)

BP SSD1 (CV)
600 mm
AXXCBL600CVCR
PCIe SSD2 (CR)

BP SSD0 (CR)
620 mm
AXXCBL620CRCR
Note: Retimer add-in card is not
compatible with R2312WFxxx

Intel S2600WF Series Specifications

General

Form Factor	2U rackmount
Memory Support	DDR4 ECC Registered DIMMs
Chipset	Intel C621
Storage Options	SATA, SAS, NVMe (depending on the specific model)
Management	Intel Node Manager
Product Type	Server Motherboard / System
CPU Socket Type	LGA 3647
Memory Type	DDR4 ECC Registered
Storage Controllers	Intel VROC
SATA Ports	10 SATA3 ports
Network Controller	Intel i350-AM4
Expansion Slots	7 x PCIe 3.0 slots (x16, x8, x4)
SAS Ports	Support through optional add-on cards
