Intel S5520SC Service Guide

Workstation Board Features
Intel® Workstation Board S5520SC Service Guide 12
Video Support
 ServerEngines* LLC Pilot II* with 64 MB DDR2 memory, 8 MB allocated to
graphics
 Dual video is supported
 On-board video available with optional accessory cable (FXXSCVDCBL)
Hard drive and optical
drive support
 Supports optical devices
 Six SATA connectors at 1.5 Gbps and 3 Gbps
 Four SAS connectors at 3 Gbps through optional Intel
®
SAS Entry RAID
Module AXX4SASMOD
USB drive support
 One internal USB port
 One internal low-profile USB port for Solid State Drive
I/O control support
 External connections:
o RJ-45 serial port A connection
o One 7.1 channel Audio connector
o One 1394 connector for IEEE1394a support
o One DH 10 serial port connector (optional)
o Two RJ-45 NIC connectors for 10/100/1000 Mb connections: Dual
GbE through the Intel
®
82575EB Network Connection,
o Four USB 2.0 ports at the back of the board
 Internal connections:
o Two 9-pin USB headers, each supports two USB 2.0 ports
o One internal USB port that supports a peripheral, such as a floppy
drive
o One DH10 serial port B header
o Six SATA connectors at 1.5 Gbps and 3 Gbps
o Four SAS connectors at 3 Gbps (optional)
o One SSI-compliant 24-pin front control panel header
o One 3-pin S/PDIF header
o One 2x5-pin audio connector
o One 2x5-pin IEEE 1394a connector
RAID Support
 Intel
®
Embedded Server RAID Technology II through on-board SATA
connectors provides SATA RAID 0, 1, and 10 with optional RAID 5 support
provided by the Intel
®
RAID Activation Key AXXRAKSW5
 Intel
®
Embedded Server RAID Technology II through optional Intel
®
SAS Entry
RAID Module AXX4SASMOD provides SAS RAID 0, 1, and 10 with optional
RAID 5 support provided by the Intel
®
RAID Activation Key AXXRAKSW5
 IT/IR RAID through optional Intel
®
SAS Entry RAID Module AXX4SASMOD
provides entry hardware RAID 0, 1, 10/10E, and native SAS pass through
mode
Security
 Trusted Platform Module
Management support
 Integrated IPMI 2.0 compliant Baseboard Management Controller.
 Support for the Intel
®
Local Control Panel (optional component sold
separately)
 Support for Intel
®
Remote Management Module 3
 Support for Intel
®
System Management Software
 Intel
®
Light-Guided Diagnostics on field replaceable units
