Feature Summary Intel® Storage System SSR212MA
8 Revision 1.4
Feature Description
Chipset Intel
®
E7520 chipset, consisting of:
 Intel
®
E7520 Memory Controller Hub (MCH)
 Intel
®
6700 PCI-X Controller Hub (PXH)
 Intel
®
ICH5-R I/O Controller Hub (ICH)
 Intel
®
8 Mb (1 MB) Firmware Hub (FWH)
Peripheral
Interfaces
Four separate and independent PCI buses using Intel® Adaptive Slot Technology
for high throughput of data via an active 2U riser board:
• Segment 1 (from baseboard): 64-bit, 133 MHz, 3.3 V, supporting the following
configuration:
o One 64-bit/133 MHz PCI-X component
 Intel
®
82546GB Dual 10/100/1000
• Segment 2 (from baseboard): 64-bit, 133 MHz, 3.3 V, Full-length PCI supporting
the following configuration:
o One riser slot 64-bit/133 MHz PCI-X
 Slot 1 SATA HBA #1.
• Segment 3 (from riser): 64-bit, 133 MHz, 3.3 V, Full-length PCI supporting the
following configuration:
o one slot: 64-bit/133 MHz PCI-X
 Slot 2 SATA HBA #2.
• Segment 4 (from riser): 64-bit, 133 MHz, 3.3 V, Full-length PCI supporting the
following configuration:
o one slot: 64-bit/133 MHz PCI-X
 Slot 3 used for FibreChannel or expanded Ethernet client
connectivity.
 One RJ-45 serial port for initial Intel Storage System SSR212MA configuration
via a local console.
 IDE interface for Disk On Module (DOM) support. .
LAN Intel
®
82546GB Dual 10/100/1000 Megabits per second (Mb/s) Ethernet Local Area
Network (LAN) Controller. Can be configured for failover or port aggregation.
Fans Support for four system fans (not supported from the Intel
®
Server Board SE7520JR2
for SSR212MA).
BIOS AMI* BIOS with support for:
 Advanced Configuration and Power Interface (ACPI)
 8 megabit symmetrical flash memory
 Support for System Management Basic Input/Output System (SMBIOS)
SSI interface
support
Server System Infrastructure (SSI)-compliant connectors for SSI interface support:
front panel, power connector.
Please refer to the Intel
®
Server Board SE7520JR2 Technical Product
Specification available at http://support.intel.com
for more information on the
Storage System SSR212MA’s server board.
