Feature Summary Intel® Storage System SSR212MA
12 Revision 1.4
1.5.4 Hard Disk Drive LEDs
The Intel
®
Storage System SSR212MA SATA HSBP contains two LEDs for each of the twelve
drive slots.
Table 1. HDD LED Function
Activity Light States
Drive Status LED
Idle Both Off
Access in Progress Green Blinking
Fault Amber On
1.6 Chassis Dimensions and Weight
Table 2. Chassis Dimensions and Weight
Height 86.7 mm 3.41 inches
Width 447 mm 17.6 inches
Depth 631 mm 24.8 inches
Weight
Chassis - as shipped (0 drives)
Chassis - fully configured (12 drives)
Shipping container
16 kilogram
27.5 kilogram
3.2 kilogram
35.2 pounds
61 pounds
7 pounds
