CA-8320 Powered Mixer
Specifications
Rated Output Power
Main Stereo 200W + 200W/4Ω
Main Bridged 400W/8Ω
Monitor 200W/4Ω
Frequency Response 20Hz – 30kHz
T.H.D.
Mixer Section Less than 0.1%
Amp Section Less than 0.5%
Input Sensitivity/Impedance
Lo-Z 50dB, 600Ω Balanced
Hi-Z -40dB, 600Ω Balanced
Tape In -10dBV/10kΩ Unbalanced
Aux In -10dB/10kΩ Unbalanced
Hum and Noise (EIN) -128dB
Crosstalk -70dB
Buss Noise -78dB
Tone Controls
High 12kHz, ±15dB
Mid 2.5kHz, ±12dB
Low 80Hz, ±15dB
Graphic Equalizer (±12dB) 63Hz, 160Hz, 400Hz, 1kHz, 2.5kHz,
6.4kHz, 12kHz
Phantom Power +48VDC
GENERAL
Mains Power Source 100V–120VAC or 220-240VAC
50/60Hz
Mains Power Consumption 517W
Weight 22kg (59 lbs)
Dimensions 480 mm(W) x 277 mm(H) x 320 mm
(D)
18.9 in (W) x 10.9 in (H) x 12.6 in (D)
Specifications and design subject to change without notice for product improvements.
