170 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
Photo transmission specific options
Additionally to “IP and GSM/GPRS specific options” described on page 168, it is
necessary to set the options below.
9.1.n.4.4 Vid dest port
The destination port is used to send the pictures to a host set up in “9.1.n.4.1
Dest name” on page 168.
9.1.n.4.5 Encryption
If the Encryption option is set to Yes, the pictures are sent encrypted with AES
algorithm.
GSM/phone specific options
9.1.n.4 Destination
The Destination menu contains the configuration of the reporting receiver.
9.1.n.4.1 Type
The Type submenu defines who receives the reports directed to the specified
central station:
• Phone: The report is sent to a specified phone number. Menu “9.1.n.4.2
Phone/User/UG” on page 171 configures this phone number.
• User: The report is sent to a specified user’s phone number. This user is
selected via menu “9.1.n.4.2 Phone/User/UG” on page 171.
• User Group: The report is sent to all users that belong to the user group that
is set via menu “9.1.n.4.2 Phone/User/UG” on page 171.
User and user group reporting require the following:
• Users must have their phone numbers set in “3.1.n.7.1 User phone” on page
87.
• The SMS reporting must be enabled for these users. See “3.1.n.7.2 SMS
reporting” on page 88.
• At least one of the user groups must allow these users to receive SMS
reports. See “3.2.n.5 User group options” on page 91).
