Installation Guide 43
7. Adjust the height of the two housing tabs by turning the
screw on which they are attached. The distance of the
tabs from the housing ring must be greater than the
thickness of the ceiling.
Housing tab
Screw
8. Make sure that the housing tab is closed and then PUSH
the housing into the pass-through hole. Hold the housing
and secure it by screwing the housing tabs down to the
mounting surface.
9. Install the trim ring.
A. Attach the trim ring to the lower dome and align the
triangular notch of the trim ring with the arrow label
on the in-ceiling mounting bracket.
B. After firmly placing the trim ring on the ceiling, rotate
the trim ring in the direction of arrow to secure the
trim ring in place.
