Appendix A — Specifications
PM23c, PM43, and PM43c Mid-Range Printer User Manual 117
PM23c Print Speed, Resolution, and General Media Specifications
Print Mode: Thermal Transfer or Direct thermal
Print Speed (variable): 203 dpi:100 to 300 mm/sec (4 to 12 ips)
300 dpi: 100 to 300 mm/sec (4 to 12 ips)
406 dpi: 100 to 250 mm/s (4 to 10 ips)
Print Resolution: 203 dpi: 8 dots/mm
300 dpi: 11.8 dots/mm
406 dpi: 16 dots/mm
Print Width: 203 dpi: 56 mm (2.20 in) max
300 dpi: 56 mm (2.20 in) max
406 dpi: 64 mm (2.52 in) max
Media Width: 19.05 to 68.6 mm (0.75 to 2.70 in)
Media Width:
(RFID Baggage Tag)
29 to 54 mm (1.14 x 2.13 in)
Label Roll Diameter
(maximum):
152.4 mm (6 in) with standard cover
184.2 mm (7.25 in) with bubble top
212.9 mm (8.38 in) with dome cover
Label Roll Core (I.D.): 76.20 mm (3 in) or 38.1 mm (1.50 in)
Label Length (minimum): 6.35 mm (.25 in)
Gap Length Between Labels: 1.20 to 26 mm (0.05 to 1.02 in)
Black Mark Length: 3 to 25 mm (0.12 to 0.98 in) centered
between tickets, 15% maximum
reflectance
Media Thickness: 61 to 264 μm (2.40 to 10.40 mil)
Media Density: 57.60 to 250 g/m2
Liner Opacity (maximum): 76% (TAPPI T425)
Ribbon Width: 21.59 to 68.6 mm (0.85 to 2.70 in)
Ribbon Roll Diameter:
(maximum)
62 mm (2.44 in)
Ribbon Core (I.D.): 25.4 (1 in)
Ribbon Core Length: 21.59 to 68.6 mm (0.85 to 2.70 in)
Gap and Black Mark Sensor: Adjustable from left edge to 50.8 mm
(2.00 in)
