Intermec EasyLAN Wireless—Interface Kit Installation Instructions 7
Chapter 1—Physical Installation
Antenna
EasyCoder PF2/4i-series printer
EasyCoder PM4i printer
Light guideCable clips
Antenna cable
EasyLAN
adapter board
#T20 Torx screw
and spacer
EasyLAN
adapter board
Light guideCable clips #T20 Torx screw
and spacer
Antenna
cable
Cable tie
Cable tie
Antenna
