Interroll RollerDrive EC310 - Product information; RollerDrive Components

12
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
External speed setting via
digital inputs
* H = logically active; L = logically inactive
Speed input on the DriveControl * Speed at gear ratio
m/s
ABC9:112:116:120:124:136:148:164:196:1
HHH1.751.310.980.780.650.440.330.250.16
H H L 1.47 1.10 0.83 0.66 0.55 0.37 0.28 0.21 0.14
H L H 1.19 0.89 0.67 0.53 0.45 0.30 0.22 0.17 0.11
H L L 0.92 0.69 0.52 0.41 0.34 0.23 0.17 0.13 0.09
L H H 0.64 0.48 0.36 0.29 0.24 0.16 0.12 0.09 0.06
L H L 0.36 0.27 0.20 0.17 0.14 0.09 0.07 0.05 0.03
L L H 0.09 0.07 0.05 0.04 0.03 0.02 0.02 0.01 0.01
L L L 000000000
