27
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Appendix
Accessories
Belt
Controls
Connection accessories
Part Properties
Toothed belt • Gates Poly-Chain GT or similar: Pitch 8 mm (0.31 in)
• Toothed belt width: 11.2 mm (0.44 in)
• Hub with 18 teeth
Round belt • Belts with 4 mm (0.16 in) and max. 5 mm (0.20 in)
diameter
PolyVee belt • Drive head with 9 grooves for flexible V-ribbed belts
• PJ form, ISO 9981, DIN 7867
• Pitch 2.34 mm (0.09 mm)
• Belts with a max. of 4 ribs
Part Part no.
DriveControl 20 S-1001415
DriveControl 54 S-1001416
ZoneControl S-1004023
SegmentControl S-1004024
ComControl S-1004025
Part Properties Part no.
Connecting cable
RollerDrive EC310 on
DriveControl
Length: 2000 mm S-1004033
