19
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Assembly
Warning notices concerning the electrical installation
All electrical work should only be performed by qualified and authorized
persons.
Disconnect the power supply before installing, removing or rewiring the
RollerDrive.
Do not apply AC current to the RollerDrive or DriveControl device at any time,
as this will cause irreparable damage.
Do not apply too much tension or load to the motor plug. Bending the cable
and forcing the star washer over the cable can cause damage to the cable's
insulation, which could result in failure of the RollerDrive.
Ensure that the RollerDrive, the DriveControl and the 24 VDC power source
are properly earthed through the conveyor frame or supporting structure in
which the RollerDrive and the DriveControl are installed. Incorrect earthing
can result in the build-up of static charge, causing the motor or DriveControl to
malfunction or fail prematurely.
Do not bend the motor cable at the motor shaft. Leave a minimum of 12 mm
(0.5 in) of excess cable for stress relief.
Give the start signal with a delay of at least 500 ms after switching on the
power supply. Switching on the power supply and the start signal at the same
time results in peak currents in excess of 5 A and damages the RollerDrive.
Risk of damage to the motor and/or RollerDrive cables
Observe the following safety information.
