11
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
DriveControls for the RollerDrive EC310
Interroll recommends using the RollerDrive EC310 in combination with the
corresponding Interroll DriveControl 20 or 54.
Speed settings
If you do not use the recommended DriveControl (see "DriveControls for the
RollerDrive EC310", page 11), you may change the speed of the RollerDrive
EC310 by altering the voltage on pin 5 of the motor plug.
Speed setting on the
DriveControl
Hint
For more detailed information on the DriveControl, please refer to the
corresponding operating manual, relevant catalogues or publications at
www.interroll.com.
DIP switch setting on the
DriveControl
Speed at gear ratio
m/s
A B C D 9:1 12:1 16:1 20:1 24:1 36:1 48:1 64:1 96:1
on on on on 1.75 1.31 0.98 0.78 0.65 0.44 0.33 0.25 0.16
on on on off 1.63 1.22 0.92 0.73 0.61 0.41 0.31 0.23 0.15
on on off on 1.51 1.13 0.85 0.68 0.57 0.38 0.28 0.21 0.14
on on off off 1.39 1.04 0.78 0.62 0.52 0.35 0.26 0.20 0.13
on off on on 1.27 0.95 0.72 0.57 0.48 0.32 0.24 0.18 0.12
on off on off 1.15 0.86 0.65 0.52 0.43 0.29 0.22 0.16 0.11
on off off on 1.03 0.78 0.58 0.47 0.39 0.26 0.19 0.15 0.10
on off off off 0.92 0.69 0.52 0.41 0.34 0.23 0.17 0.13 0.09
off on on on 0.80 0.60 0.45 0.36 0.30 0.20 0.15 0.11 0.07
off on on off 0.68 0.51 0.38 0.31 0.25 0.17 0.13 0.10 0.06
off on off on 0.56 0.42 0.32 0.25 0.21 0.14 0.11 0.08 0.05
off on off off 0.44 0.33 0.25 0.19 0.17 0.11 0.08 0.06 0.04
off off on on 0.32 0.24 0.18 0.15 0.12 0.08 0.06 0.05 0.03
off off on off 0.21 0.15 0.12 0.09 0.08 0.05 0.04 0.03 0.02
off off off on 0.09 0.07 0.05 0.04 0.03 0.02 0.02 0.01 0.01
off off off off Stop or in accordance with the signals on the Speed A-C ports
