Interroll RollerDrive EC310 User Manual

15
Version 2.1 (08/2013) en
Translation of the original instructions
RollerDrive EC310
Product information
BF/EL = Between Frames / Installation Length
PolyVee head IP66
Toothed belt head Poly-Chain GT; 8 mm pitch; 18 teeth
Sprocket head 11 mm (0.44 in) hex shaft; 3/8 in pitch;
20 teeth
11 mm (0.44 in) hex,
spring-loaded shaft
Female threaded M8 (FTM8) shaft pin
4 mm (0,16 in)
31 mm (1,22 in)
%)(/
ø43 mm (1,7 in)
SW 13 mm (0,51 in)
3
5 mm (1.38 in)
%)(/
27.5 mm (1.08 in)
4 mm (0.16 in)
ø45.8 mm (1.8 in)
AF 11 mm (0.43 in) hex
9.5 mm (0.37 in)
16.8 mm (0.66 in)
35 mm (1.38 in)
%)(/
ø60.9 mm (2.4 in)

Interroll RollerDrive EC310 Specifications

General

Brand	Interroll
Model	RollerDrive EC310
Category	DC Drives
Language	English
