Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
103
Outdoor DC PoNE, Continued
Pole and wall installation procedure, continued
Step Action
3
Prepare and terminate the grounding cable as instructed to Appendix D: Cables
Termination.
Use the tool with TORX T10 bit to install the grounding cable, as shown below.
Do not over tighten. Adjust the tool for max tightening torque 0.9 Nm.
Continued on next page
