Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
37
Fiber Optic cable for service Traffic and Inband Management
/ Gigabit Ethernet (S-FTP) cable for service Powering
Fiber optic
cable length
restrictions
The following tables shows the maximum length of optical fiber cables in
combination with the SFP type:
Optical Fiber Cable Lengths combined with Gigabit Ethernet SFP:
Optical Fiber Cable Type
SFP Details / Order Code
Max Length (m)
Single mode
1000 Base-LX
5,000
1000 Base-LX10
(SFP-SM-10KM)
10,000
1000 Base-EX
(SFP-SM-40KM)
40,000
1000 Base-ZX
(SFP-SM-80KM)
80,000
OM1 (62.5/125) Multi-mode
1000 Base-SX
(SFP-MM-500M)
275
OM2 (50/125) Multi-mode 550
Continued on next page
