4. Installation Procedures
52
4.1. Radio Unit and Antenna
Sectoral and Parabolic Antenna
Introduction
Apply this procedure for installing the OSDR to sectoral/parabolic antenna.
For sectoral antennas the procedure includes the alignment steps,
also.
The antenna is capable to be installed in both side of the pole. The
following photos are indicative of the installation in the left orientation
of the sectoral/parabolic models.
Prerequisites
It is very important to mount the antenna exactly as described to
INSTALLATION INSTRUCTION LEAFLET (included in the antenna
package).
Tools and
materials
# Description
Tools
• Adjustable torque U-wrench.
• Allen key.
Materials OSDR and antenna.
Continued on next page
