Antennas
Antenna types
#
Description
A Antenna, sectoral 90
0
, integrated,
26/28/32 GHz.
Includes:
• Mounting kit.
• Greasing paste.
• Installation leaflet.
B Antenna, sectoral 90
0
, integrated,
10.5 GHz.
Includes:
• Mounting kit.
• Greasing paste.
• Installation leaflet.
C Antenna, parabolic, 0.3 m, integrated,
10.5/26/28/32 GHz.
Includes:
• Mounting kit.
• Greasing paste.
• Installation leaflet.
D Antenna
(1)
, panel, 10.5 GHz.
For installation requires the following
order codes:
• OSDR-ANT-MNT (mounting kit).
• GRS-PST (greasing paste).
For antennas order codes please refer to item 2 of Reference
manuals on page 3.
(1)
Extra bolts and leaflet concerns only WiBAS
TM
-Connect installation.
