4.3. Radio Unit Ethernet (S-FTP) Cable
Introduction
Apply this procedure for installing the Ethernet (S-FTP) cable with M20 gland
to OSDR receptacle (GbE2 or FE).
Prerequisites
How to terminate an Ethernet (S-FTP) cable please refer to Appendix D:
Cables Termination.
Tools and
materials
#
Description
Tools Adjustable torque U-wrench.
Materials
• M20-GLAND.
• Terminated Ethernet (S-FTP) cable to RJ-45 jack.
