Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
53
Sectoral and Parabolic Antenna, Continued
Procedure
To install the OSDR onto the sectoral/parabolic antenna and to perform
antenna alignment, proceed as follows:
1 The antenna installation should look as follows.
Continued on next page
