Intracom OSDR - Page 3

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
-I-
Document Revision History
Previous Edition: 2.2
Current Edition: 3.0
Reasons of Change
M
= Modified,
A
= Added,
R
= Removed
Details
New materials (M) (A)
New installation procedures (A)
• Sectoral 26/28/32 GHz antenna
• Sectoral 10.5 GHz antenna
• Parabolic antenna 10.5/26/28/32
GHz
• M20 gland
• Outdoor AC PoNE
• Indoor AC PoNE
• XPOL tool kit
Contents restructure (M) Document optimization
Revised installation instructions (M)
• OSDR to sectoral/parabolic
antenna
• OSDR to panel antenna
• Panel antenna mounting kit
• ETH cable installation
• Optical cable installation
• Power injectors installation
• Sectoral antenna pole space
requirements
