4. Installation Procedures
64
Sectoral and Parabolic Antenna, Continued
Procedure, continued
Step Action
21
Use the U-wrench tool to perform azimuth adjustment
(1)
, as shown below.
• Do not over tighten.
• For maximum tightening torque please follow the antenna installation leaflet
(available in package).
End of procedure for sectoral 10.5 GHz.
End of procedure.
(1)
The values must be taken from RF planning team.
