Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
73
Panel Antenna, Continued
Panel antenna
installation
procedure,
continued
3 Perform the following actions:
A: Lubricate the O-ring with silicone grease.
B:
Remove antenna protection plastic sticker from the
feeder.
4 Unlock the four radio unit clamps, as shown below.
Continued on next page
