Appendix A: Adaptation Kit Installation
92
Pole Installation, Continued
Procedure
To install adaptation kit onto the pole, proceed as follows:
Step Action
1 Choose the proper hose clamps based on the pole diameter.
2 Pass through the clamps to bracket, as shown below:
3
Choose the correct position onto the pole to install the
adaptation bracket.
4 Use the tool to tighten.
Do not over tighten. Adjust the tool for tightening
torque, as follows:
• min 5.5 Nm.
• max 7.0 Nm.
Continued on next page
