SECTION 4—SEAT/BACK
14
S E C T I O N 4 — S E A T / B A C K
W A R N I N G
The seat height, seat depth, back angle, seating system, size/position of the rear
wheels, size/position of the front castors, seating options (e.g. headrest, back
bag, …) as well as the user condition directly relate to the stability of the
wheelchair. Any change to one or any combination of the nine may cause the
wheelchair to decrease in stability. Refer to table on page 6.
After ANY adjustments, repair or service and BEFORE use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur.
Removing Back-Canes
NOTE: For this procedure, refer to FIGURE 4.1.
1. Remove the mounting screw and locknut (M6) that secures the back-cane to the
back-cane bracket.
2. Repeat STEP 1 for the other back-cane.
3. Remove the back canes out of the back-cane brackets.
FIGURE 4.1
Removing Back-Canes
Removing/Installing Seat Upholstery
NOTE: For this procedure, refer to FIGURE 4.2, next page.
Removing Seat Upholst ery
NOTE: To install the seat upholstery, reverse this procedure.
