SECTION 9—ANTI-TIPPERS
Installing/Adjusting Headrest
W A R N I N G
After ANY adjustments, repair or service and before use, make sure all
attaching hardware is tightened securely - otherwise injury or damage
may occur.
Installing Headrest
NOTE: For this procedure, refer to FIGURE 8.2.
1. Install the back brace. Refer to Installing removing the back brace paragraph.
2. Set the Headrest bracket (mounting bolts, headrest bracket and the hand wheel A)
in the fixing holes on the back brace tube.
3. Introduce the vertical tube that support the headrest cushion into the headrest
bracket.
4. Adjust to the appropriate height position with the user sat into the chair, tighten the
hand wheel A.
5. Adjust the headrest cushion (depth and angle position) and tighten securely the
screws C and the handle D.
FIGURE 8.2 Installing Headrest
