Assembly-Force-2Only
8.
Placethesecondclampovertheframeandthefork/frame
attachmentplate.
9.
Securelytightentheupperandlowerclamps.Thereshould
be1/8inch(0.3175cm)gapbetweentheframeandfork/frame
attachmentplate.
CAUTION!
–Donotovertighten.
10.
Looselytightenthedampenerbolttoholdtheforkinplace.
11.
Tocenterthefrontwheel,tightenthesetscrewsoneachsideof
thedampenerplate.Afterthefrontwheeliscentered,tighten
thedampenerscrew.
1171790-B35
