1.Ifapplicable,removetheseatupholstery.Referto6.14Replacing
SeatUpholstery,page65.
2.Adjusttheseatposition:
a.Force,Force-2andForceGModels:Loosen,butdonot
removethetwomountingboltsandlocknutsAsecuringthe
twobackclampsBtotheseatrailsC.Slidebackclamps
Bfor(forward)oraft(rearward)alongtheseatrailsto
desiredseatposition.
3.SecurelytightenthetwomountingboltsandlocknutsA.
4.Ifapplicable,installtheseatupholstery.Referto6.14Replacing
SeatUpholstery,page65.
5.Ifnecessaryadjustthebackangle.
AdjustingSeats(ForceRX)
WARNING!
–ThisprocedureisnotapplicableforForce-2,ForceG
andForceCCmodelhandcycles.
–Seatshouldbeadjustedsothatwhenseatedwithfeet
inthefootrests,thereisaslightbendattheknee
andaslightbendattheelbowwhenthehandpedalis
furthestaway.
1.RemoveboltDfromcarbonbackAandwheelchairframeB.
2.AdjustcarbonbackAtodesireddepthandalignmountinghole
CincarbonbackAwithholeinhandcycleframeB.
3.InsertboltDincarbonbackAandhandcycleframeB.
4.Tightensecurely.
5.10AdjustingBackAngle
CAUTION!
–ThefollowingdirectionsareforForce-2,ForceG,
andForceCC.
–Donotattempttousethefollowingdirectionswith
ForceRX.
