Invacare Force-2 - Replacing the Crank Arms

TopEnd
®
Force™
Installing
Foreaseofinstallation,securethehandcycleframe
approximately6inches(15.24cm)fromthegroundorseek
assistance.
1.LoopthechainAoverthefrontwheelsprocketB.
2.PositionthefrontwheelaxleCintotheforkslotsD.
3.Tightentheknobontheoppositesideofthequick-releaselever
EandsecurethewheelCtotheforkDwiththequick-release
leverE.
6.6ReplacingtheCrankArms
Rightandleftaredeterminefromtheuserseatedonthe
handcycle.
ReplacingtheLeftSideCrankArms
Refertoimageonnextpage.
1.RemovethetwosocketscrewsAfromtheexistingcrankarm
clampH.
2.RemovesocketscrewandcapfromthespindleC.
3.UsesocketscrewAfromcrankarmB(inthecenterhole)
toopenbinderofcrankarm.
4.RemovetheexistingcrankarmBfromthespindleC.
5.PositionthenewcrankarmBontothespindleCsothatthe
newcrankarmBisevenlyalignedwiththerightsidecrank
armD.
6.ReinstallthesocketscrewandcapfromthespindleC.DO
NOTovertighten.
7.UsingthetwosocketscrewsA,securethenewcrankarm
clampHtothespindleC.Securelytighten.
581171790-B
